#include <Selector.h>

Collaboration diagram for Selector:

Public Member Functions
	Selector ()
	~Selector ()
void	add_child (Selectee *P)
void	delete_child (int fd_in)
int	update_flags (int fd_in, int flag)
void	set_gflag (unsigned gflag_index)
void	event_loop ()
Static Public Member Functions
static int	gflag (unsigned gflag_index)
Static Public Attributes
static const int	Sel_Read = 1
static const int	Sel_Write = 2
static const int	Sel_Except = 4
static const int	Sel_Timeout = 8
Private Member Functions
virtual int	ProcessTimeout ()
virtual Timeout *	GetTimeout ()
Private Attributes
SelecteeMap	S
bool	children_changed
int	gflags

Detailed Description

Definition at line 31 of file Selector.h.

Constructor & Destructor Documentation

Selector::Selector ( )

Definition at line 7 of file Selector.cc.

References children_changed, and gflags.

Selector::~Selector ( )

Actually does nothing.

Definition at line 15 of file Selector.cc.

Member Function Documentation

void Selector::add_child ( Selectee * P )

Adds the Selectee as a child of the Selector. This adds the Selectee's fd to the list of fds in the Selector's select() call, depending on the Selectee's flags.

Definition at line 23 of file Selector.cc.

References children_changed, Selectee::fd, nl_error, S, and Selectee::Stor.

void Selector::delete_child ( int fd_in )

Removes Selectee from the Selector and deletes the Selectee. Note that this is for use in a special case where the fd is being closed and the child needs to be deleted, but the caller does not know the mapping from the fd to the Selectee. In the usual case, the Selectee is deleted by its owner after the event_loop has exited, and it is unnecessary to explicitly remove the Selectees as children of the Selector.

Definition at line 41 of file Selector.cc.

References children_changed, Selectee::fd, nl_assert, nl_error, and S.

void Selector::event_loop ( )

Loops waiting on select(), using the fds and flags of each Selectee registered via add_child(). When select() indicates that an fd is ready, the corresponding Selectee's ProcessData() method is invoked with the flag value indicating what action is ready.

Definition at line 93 of file Selector.cc.

References children_changed, Selectee::fd, Selectee::flags, Selectee::GetTimeout(), GetTimeout(), gflags, nl_error, Selectee::ProcessData(), ProcessTimeout(), S, Sel_Except, Sel_Read, Sel_Timeout, Sel_Write, TimeoutAccumulator::Set_Min(), and TimeoutAccumulator::timeout_val().

Here is the call graph for this function:

Timeout * Selector::GetTimeout ( ) [private, virtual]

Virtual method to allow Selector to bid on the select() timeout along with the Selectee children. The minimum timeout value is used.

Returns:: a Timeout * indicating the requested timeout value or NULL.

Definition at line 167 of file Selector.cc.

Referenced by event_loop().

Here is the caller graph for this function:

static int Selector::gflag ( unsigned gflag_index ) [inline, static]

Method to map a global flag number to a bit mask to be set in a Selectee's flags word.

Parameters:

gflag_index global flag bit number

Returns:: bit mask selecting the specified global flag.

Definition at line 49 of file Selector.h.

Referenced by set_gflag().

Here is the caller graph for this function:

int Selector::ProcessTimeout ( ) [private, virtual]

Virtual method called whenever select() returns 0. The default does nothing, but it can be overridden.

Returns:: non-zero if the event loop should terminate.

Definition at line 160 of file Selector.cc.

Referenced by event_loop().

Here is the caller graph for this function:

void Selector::set_gflag ( unsigned gflag_index )

Sets a bit in the global flags word. Selectees can set a corresponding bit in their flags word to request notification when the bit gets set. The function Selector::gflag(gflag_index) returns the bit that corresponds to set_gflag(gflag_index). gflag_index can take on values from 0 to 8*sizeof(int)-4.

Definition at line 81 of file Selector.cc.

References gflag(), gflags, and nl_assert.

Referenced by TM_Selectee::ProcessData().

Here is the call graph for this function:
